Resources
In efforts to keep our customers safe and informed, the towing pros at Croft Trailer Supply have put warranty information, wiring diagrams, installation and assembly instructions, and federal and state regulations all in one place. Any information you may need when it comes to towing products, trailers and supplies is available on Croft Trailer Supply’s resources page. If you can’t find what you’re looking for email us.
Wiring Diagrams
Parts Breakdown for Electric Brakes
- 23-26 or 23-27 10" x 2-1/4" Dexter, 3.5k
- 23-468 or 23-469 10" x 2-1/4" Dexter Nev-R-Adjust, 3.5k
- 23105 or 23106 12" x 2" Dexter, 6k
- 23-464 or 23-465 12" x 2" Dexter, Nev-R-Adjust, 7k
- 23180 or 23181 12" x 2" Dexter, 7k
- 23428 or 23429 12-1/4" x 2-1/2" Dexter, 7.2k
- 23434 or 23435 12-1/4" x 3-3/8" Dexter, 8k
- 23-450 or 23-451 12-1/4" x 3-3/8" Dexter, 9k - 10k GD
- 23-438 or 23-439 12-1/4" x 4" Dexter, 10k HD
Parts Breakdown for Hydraulic Brakes
- 40715M or 40716M 10" x 2-1/4" Demco, 3.5k Free-Backing
- 23-344 or 23-345 10" x 2-1/4" Dexter, 3.5k Free-Backing
- 3201909M or 3201910M 10" x 2-1/4" Demco, 3.5k Uni-Servo
- 3201917M or 3201918M 12" x 2" Demco, 6k Uni-Servo
- 3201915 or 3201916 12" x 2" Titan, 6k Duo-Servo
- 42028M or 42029M 12" x 2" Demco, 6k Free-Backing
- 23-342 or 23-343 12" x2" Dexter, 7k Free-Backing
