SURE-TRAC DIFFERENCE - HYDRAULIC DUMPS HD
Offering best-in-class payload capacity and dependability, SURE-TRAC Dump Trailers are the smart choice and offer the widest variety of models in the industry. Whether you are looking to spruce up your property or tackle commercial clean-ups, we offer a dump trailer to help you successfully complete any job.
The SCISSOR hydraulic lift system contains a hydraulic cylinder within a hoist mounted to the underside of the trailer. This scissor hoist provides additional structural stability, increasing the rigidity between the dump bed and the dump frame. The scissor hoist provides the fastest cycle time of the different hoists, and the power-up and gravity-down reduces battery power and provides more cycles per charge.
Multi-Function Gate Evenly distribute your load with the spreader option or open the barn doors for easy access.
Underbody Tool Storage Secure storage for your tools while on the job or while sitting outside.
110 Volt Battery Charger Easy access to charge your battery.
Integrated Side Panels A smooth and sleek appeal that provides more structural support.
Tarp Kit Secure loose materials for a safer transport.
Approximated Dump Capacity of this trailer: 10000 lb
Product Videos
- Location:
- Kansas City
- Model Number:
- STD8014TA5
- Color:
- Black
- Year:
- 2026
- Manufacturer:
- Sure-Trac
- Interior Bed Width:
- 6'10" (82")
- Overall Trailer Width:
- 8'6" (102")
- Overall Trailer Height:
- 4'8" (56")
- Interior Bed Length:
- 14' (168")
- Overall Trailer Length:
- 18'6" (222")
- Interior Wall Height:
- 24"
- Deck Height:
- 29"
- Adjustable Coupler Height:
- 19"-27"
- Payload Capacity:
- 10200
- Axle Capacity:
- 7000
- GVWR:
- 14000
- Frame:
- 6" x 2", 3/16" Tube Steel Frame
- Curb Weight:
- 3800
- *:
- Integrated Side Body Stiffening System
- *:
- Board Holders
- *:
- Adjustable 2-5/16 Coupler
- *:
- Safety Chains
- *:
- 7-Way RV-Style Molded Plug
- *:
- Breakaway Switch with Battery
- *:
- EverLink™ Wiring Harness
- *:
- Sealed Brake Connections
- *:
- HD 12K Dropleg Jack
- *:
- Stabilizer Jack Receivers
- *:
- 78" x 18" Ramps (Stored Underneath Bed)
- *:
- HD Reinforced Combo Barn Door Spreader Gate w/Cambar
- *:
- HD Double Broke Tread Plate Fenders
- *:
- HD Slipper Spring Axles w/ EZ Lube Hubs
- *:
- Self Adjusting Electric Brakes on Both Axles
- *:
- 16" Radial Tires (235/80R16 LRE)
- *:
- Zinc Rich High Gloss Powder Coat Finish
- *:
- Bead Blasted, Iron Phosphate Washed Steel Prep Process
- *:
- 10-Gauge Floor
- *:
- (5) 1/2" D-Rings
- *:
- Stake Pockets
- *:
- Spare Tire Carrier
- *:
- Integrated Tarp Mount
- *:
- Mesh Tarp Kit (Installed)
- *:
- Tongue Mounted HD Control Box with Key Lock
- *:
- Deep Cycle Battery
- *:
- Battery Charger, 110V
- *:
- Underbody Secure Tool Storage
- *:
- All LED Lights
- *:
- 3-Year Manufacturer Warranty!
